DIN Rail / Wall Mount UN Managed Industrial Ethernet Switches 6
Port
HY-524GI through a rugged, energy-efficient, industrial
10/100/1000Mbps Ethernet switch for critical applications in
hazaedous environments, such as smart traffic, factory automation
and outdoor access connection for video surveillance / FTTx and
Wi-Fi coverage.
SINOHONE industrial ethernet switches give you full/half-duplex
auto-negotiation and auto MDI/MDIX operation, enabling you to
connect your network devices quickly and easily with little to no
configuration required. Reduce your energy costs with
Energy-Efficient Ethernet with lower overall power consumption, the
Ethernet switch enhances your energy efficiency, in turn helping
you reduce monthly costs.
Conquer the tough demands of industrial environments designed with
a rugged IP40 rated housing, the networj seitch delivers maximum
performance even in harsh industrial conditions. Its wide-range
terminal block input gives you the flexibility to power the switch
as required, based on your own power input source, while its wide
operationg termperature range keeps your network running smoothly.
Get up and running in no time. This industrial ethernet switch is
easy to install with an attached mental bracket for DIN rain
mounting on equipment racks and cabinets.
Characteristics
- Compact 6-port Ethernet switch (4 Ports PoE support) with automatic
MDI/MDI-X crossover for plug-and play
- Expand your network connectivity with this rugged unmanaged network
switch, easy monitor and diagnostic by LED indicator
- FAST DATA TRANSMISSION: Each port supports both 10/100Mbps speed
auto negotiation, Supports IEEE 802.3, 802.3u, 802.3x, 802.3af
(power over Ethernet)
Industrial over enterprise
Industrial network switches are built to work in harsh conditions
such as manufacturing, transport, maritime, oil & gas, and mining.
They are designed for high availability over long periods because
downtime costs in industrial environments are often considerable.
Business IT switches may have a lifecycle of only 1.5 to 3 years;
industrial Ethernet switches may be kept working for 10 years or
more.
Specification
| Model | HY-524GI |
|
| Number of interfaces | 4 Gigabit electrical ports 2 Gigabit SFP ports |
|
| Exchange capacity | 53G |
| Packet forwarding rate | 8.9Mpps |
| POE power supply | no |
| Operating temperature | -40 to 80 °C |
| Input voltage | 12 ～ 48VDC |
| Protection level | IP40 |
| shell | Metal material, no fan |
| Operating temperature | -40 to 80 °C |
| storage temperature | -40 to 85 ° C |
| Working humidity | 5 to 95% (no solidification) |
Related Models
| HY-505 | 5 hundred megabytes |
|---|
| HY-508 | 8 hundred megabytes |
|---|
| HY-504G | 4 Gigabit electrical ports |
|---|
| HY-508G | 8 full Gigabit ports, backplane bandwidth 16G, packet forwarding
rate 11.9M, 12VDC, 1A |
|---|
| HY-5016G | 16 Gigabit electrical ports |
|---|
| HY-5024G | 24 Gigabit electrical ports |
|---|
| HY-515 | Provide 1 Gigabit SFP port (or specify other optical port form), 5
100M electrical ports |
|---|
| HY-524 | Provide 2 Gigabit SFP ports (or specify other optical ports), 4
100M electrical ports |
|---|
| HY-528 | Provide 2 Gigabit SFP ports (or specify other optical ports), 8
100M electrical ports |
|---|
| HY-515G | Provide 1 Gigabit SFP port (or specify other optical port form), 5
Gigabit electrical ports |
|---|
| HY-524G | Provide 2 Gigabit SFP ports (or specify other optical ports), 4
Gigabit electrical ports |
|---|
| HY-528G | Provide 2 Gigabit SFP ports (or specify other optical ports), 8
Gigabit electrical ports |
|---|
| HY-5216G | Provide 2 Gigabit SFP ports (or specify other optical ports), 16
Gigabit electrical ports |
|---|
| HY-5224G | Provide 2 Gigabit SFP ports (or specify other optical ports), 24
Gigabit electrical ports |
|---|
