Black Din Rail Gigabit Ethernet Switch 4 1000m Sfp Fx Ports + 8 10/100/1000m Tx Ports

Factory directly supply 4 1000M SFP FX ports + 8 10/100/1000M TX ports DIN Rail Gigabit managed Industrial

Description

HY-648I is one of our industrial grade switch. The product provides high-speed Ethernet service access and supports Ethernet standard protocols.

It has the ability to connect with PTN, simplify the operation interface, make the network maintenance means effective and unified, and help to achieve efficient network management. It simplifies the complex protocol overhead of PTN and provides the OAM capability of the service layer, which makes the design and implementation of the access network more general.

Specification

Product Name	DIN Rail Gigabit Managed Switch
Model No.	HY-648I
Number of interference	100/1000M SFP ports (or specify other optical port forms):4 Gigabit ports :8
POE power supply	Non Support
Exchange capacity	53G
Mpps	17.85Mpps
PTN ring network	PTN industrial ring network technology, using ERPS protocol, STP protocol
Management	Support local Console serial port and TELNET command line management; Support SSH; Support SNMP, WEB management; Support the unified management through the EMS management system independently developed by our company; Support remote device software upgrade and backup through FTP and TFTP; Support RMON performance statistics for ports
Power and power supply	No fan, low power consumption, the total power consumption of the equipment is less than 10/15W Industrial grade supports dc or ac power (dc parameters: default -48v: -36v ~ -72v, ac parameters: default 220V: 100V ~ 260V)
Other features	Port convergence /LACP supported, support 1:1 port protection Support interport protection based on the LACP protocol, linear protection based on the G.8031 protocol and ring network protection based on the G.8032 protocol Support port redirection and port mirror function, support port-based failover capabilities Support MSTP/RSTP protocol Support fiber breakage alarm;Support power failure warning of Dying Gasp remote device Support equipment online upgrade Support storm suppression and port speed limit, speed limit granules up to 64K Support SLA, Link performance tests such as link delay, jitter, packet loss and throughput can be implemented Support port-based, 802.1p, DSCP, TOS, MAC address, VLAN ID, Ethernet Type
Operating temperature	Industrial grade: (-40 ° C~ 80 ° C)
Storage temperature	-40°C～85°C

Applications

Metallurgical, petroleum and petrochemical, road traffic control automation
Building automatic control system, oilfield control automation
Hydropower station control automation
Computer room monitoring system, water conservancy monitoring, environmental protection monitoring and other industrial automation places
