10/100base-T To 100base-X Media Converter SC Industrial POE Media Converters

Product Description

Item	10/100 Poe Industrial Fiber Optic Media Converter
Number of interfaces	SFP ports (or specify other optical port forms):1
Number of interfaces	Electrical ports (POE power supply):2
Exchange capacity	53G
Mpps	10/100Mbps RJ45 Ports
POE power supply	Support
Power Consumption	Max.3.5W
Levels of protection	IP40
Model No.	HY-512I
Exchange Capacity	53G
Power and power supply	No fan, low power consumption, the total power consumption of the equipment is less than 10/15W
Power and power supply	Industrial grade supports dc or ac power (dc parameters: default -48v: -36v ~ -72v, ac parameters: default 220V: 100V ~ 260V)
Other features	Port convergence /LACP supported, support 1:1 port protection
	Support interport protection based on the LACP protocol, linear protection based on the G.8031 protocol and ring network protection based on the G.8032 protocol
	Support port redirection and port mirror function, support port-based failover capabilities
	Support MSTP/RSTP protocol
	Support fiber breakage alarm;Support power failure warning of Dying Gasp remote device
	Support equipment online upgrade
	Support storm suppression and port speed limit, speed limit granules up to 64K
	Support SLA, Link performance tests such as link delay, jitter, packet loss and throughput can be implemented
	Support port-based, 802.1p, DSCP, TOS, MAC address, VLAN ID, Ethernet Type
Operating Temperature	Industrial grade: (-40 ° C~ 85 ° C)
Storage temperature	-40°C~80°C

Characteristics

Industrial design, 2x 10/100M Ethernet RJ45 ports with AutoUplink™ and 1x 100M SC optical port
Supports IEEE802.3x flow control for Full-duplex Mode and back pressure for Half-duplex Mode
RJ-45 port supports Auto MDI/MDI-X
Automatic MAC address learning and aging
Auto-Negotiation for Full-duplex Mode and Half-duplex Mode
Plug and play, with LED indicators for monitoring power/link/activity, easy to use.
Provides DIN35 rail-type installation method
Electromagnetic compatibility of up to 4 grade standard
IP40 protection class
Superior performance, successfully used in industrial field
Default PoE power supply type is end-span, mid-span optional
Power ports supports both IEEE802.3af and IEEE802.3at standard PoE power supply.
