Armored Hybrid Fiber Power Cable Data Power Composite Electric Utilities

Ask Lasest Price
Brand Name :	SINOHONE
Model Number :	OPGW
Certification :	CPR FCC CE RoHS ISO9001
Price :	USD $0.38~$0.58 / meter
Payment Terms :	L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :	500000 meters per month
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

Armored Hybrid Fiber Power Cable Data Power Composite Electric Utilities

Data And Power Composite Cable Hybrid Fiber Power Cable Armored Electric Utilities

Description:

Sinohone hybrid fiber / power cable offers the nearly unlimited bandwidth of fiber optic connections in combination with power feeding in the same cable.

Typical applications for our hybrid cable are fiber to the antenna (FTTA) for cellular system, Wifi hotspots, sensor networks, surveillance cameras etc.

Applications:

For use by electric utilities on transmission lines in lieu of traditional shield wire
For retrofit applications where existing shield wire needs to be replaced with OPGW
For new transmission lines instead of traditional shield wire.
Voice, video, data transmission
SCADA networks
Dark fiber leasing

Characteristics:

Can be installed without shutting off the power
Excellent AT performance, The maximum inductive at the operating point of AT sheath can reach 25kV
Light weight and small diameter reducing the load caused by ice and wind and the load on towers and backprops
Large span lengths and the largest span is over 1000m
Good performance of tensile strength and temperature
The design life span is 30 years
Working temperature: -40°C ~ +70°C

Specifications:

			2-96 fibers	98-288fibers
Max. Tension (N)	Short-term		1500	3000
Max. Tension (N)	Long-term		600	1000
Max. Crushing Resistance (N/100mm2)			1000
Temperature range(°C)			-40°C– +70°C
Min. Bending Radius(mm)		Install	20D
Min. Bending Radius(mm)		Static	10D

		G.652	G.655	50/125μm	62.5/125μm
Attenuation	@850nm			≤3.0 dB/km	≤3.0 dB/km
(+20℃)	@1300nm			≤1.0 dB/km	≤1.0 dB/km
	@1310nm	≤0.36 dB/km	≤0.40 dB/km
	@1550nm	≤0.22 dB/km	≤0.23dB/km
Bandwidth (Class A)	@850nm			≥500 MHz·km	≥200 MHz·km
Bandwidth (Class A)	@1300nm			≥1000 MHz·km	≥600 MHz·km
Numerical Aperture				0.200±0.015NA	0.275±0.015NA
Cable Cut-off Wavelengthλcc		≤1260nm	≤1480nm
