The term "patch" came from early use in telephony and radio studios, where extra equipment kept on standby could be temporarily substituted for failed devices. This reconnection was done via patch cords and patch panels, like the jack fields of cord-type telephone switchboards.

Structural features

Main technical Specifications

Operations

1. Peel the cable , take off the outer and inner housing, as well as loose contract tube, and wash off the filling grease, leaving 1.1～1.6m fiber and 20～40mm steel core.
2. Fix the cable-pressing card and the cable, as well as the cable reinforce steel core.
3. Lead the fiber into the melting and connecting tray, fix heat contract tube and melted tube to one of the connecting fiber. After melting and connecting the fiber, move heat contract tube and melted tube and fix the stainless (or quartz) reinforce core stick ,make sure the connecting point is in the middle of the housing pipe. Heat the pipe to make the two into one.Put the protected joint into the fiber-laying tray.(one tray can lay12 cores)
4. Lay the left fiber in the melting and connecting tray evenly, and fix the winding fiber with nylon ties. Use the trays from the bottom up. After all the fiber has been connected, cover the top layer and fix it.
5. Position it and use the earth wire in accordance with the project plan.

Sichuan Hone Technology Co., Ltd. is specialized in information and communications network products. Our company is mainly engaged in Intelligen Switches, Industrail Switches, Optical Fiber Cables, LAN Cables and related accessories products etc.

We have rich experience in the optical communication industry and great capability of R&D, design and construction. All of our products have passed the ISO 9001 quality system certification, international ROHS, CE, CPR and FCC certification. Also, we accept OEM/ODM service, we are committed to cost-effective solutions to create new values for our partners.
